Binzel ABICOR BINZEL supplies for all working materials and applications the exact welding or cutting torch necessary. For the manual use or for the semi-or full automatic operation. Gas- or liquid-cooled. Wide range welding accessories as well as robotic peripheral systems.

Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose

Part No. 600.PACK

Quick Overview

The Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose is a mobile extraction unit designed to remove welding fume at the source.

The cleaning of the collected particles is 100% automated thanks to a regular compressed air pulse that ensures that all collected small particles are blown out and collected in a dust collection container.

This is easily emptied in daily standard operation, eliminating maintenance downtimes. The filter gets cleaned automatically by compressed air impulse. The unit is equipped with 4 robust castors, for a high mobilty.

PLEASE NOTE THIS UNIT IS NOT SUPPLIED WITH THE STANDARD 110 V PLUG.

Delivery cost: £0

Availability: In Stock - Please call for latest delivery details

£2,895.00 Excl. VAT £3,474.00 Inc. VAT

Qty:

Download Data Sheet

Product Details
Technical Specification
Related Products

Product Details

Features:

110 V
Powerful fume extraction technology: more than 20.000 PA negative pressure
100% automated filter cleaning
Filters out up to 99.99% of all dusts > 0.1 m
Reduces operating costs and wear thanks to automatic start/stop - optionally via current clamp
Small, robust size with castors for maximum mobility
Supplied with a RAB Grip 255 LW BBH Welding Torch & a 5 m Hose

Service & Support For

Dust & Fume Extraction

Find out more

Technical Specification

Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose

Dimensions (LxWxH)	700 x 700 x 1000 mm
Voltage	110 V - 50/60 Hz
Power Consumption	2 x 0.8 kW
Max. Negative Pressure	20.000 PA
Max. Airflow	340 m³/h
Cleaning	Automatic
Weight	35 kg
Connection Diameter	60 mm
Filter Efficiency	99.99%
Sound Level	< 68 dB(A)
