Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose

Part No. 600.PACK

The Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose is a mobile extraction unit designed to remove welding fume at the source.

The cleaning of the collected particles is 100% automated thanks to a regular compressed air pulse that ensures that all collected small particles are blown out and collected in a dust collection container.

This is easily emptied in daily standard operation, eliminating maintenance downtimes. The filter gets cleaned automatically by compressed air impulse. The unit is equipped with 4 robust castors, for a high mobilty.


Shipping outside UK - Contact us
Next Day Delivery
£3,354.00 £2,795.00
Get in touchIs this the right product for you?Ask us a question
ABICOR BINZEL supplies for all working materials and applications the exact welding or cutting torch necessary. For the manual use or for the semi-or full automatic operation. Gas- or liquid-cooled. Wide range welding accessories as well as robotic peripheral systems.

Product Details


  • 110 V
  • Powerful fume extraction technology: more than 20.000 PA negative pressure
  • 100% automated filter cleaning
  • Filters out up to 99.99% of all dusts > 0.1 m
  • Reduces operating costs and wear thanks to automatic start/stop - optionally via current clamp
  • Small, robust size with castors for maximum mobility
  • Supplied with a RAB Grip 255 LW BBH Welding Torch & a 5 m Hose

Spare Parts

Purchasing spares,
made easy.

Service & Support For

Dust & Fume Extraction

Find out more

Technical Specification

Binzel XFume iVac 110 V & Torch RAB Grip 255 LW BBH + 5M Hose
  Dimensions (LxWxH)    700 x 700 x 1000 mm
  Voltage   110 V - 50/60 Hz
  Power Consumption    2 x 0.8 kW
  Max. Negative Pressure    20.000 PA
  Max. Airflow    340 m³/h
  Cleaning   Automatic
  Weight   35 kg
  Connection Diameter   60 mm
  Filter Efficiency   99.99%
  Sound Level   < 68 dB(A)
